Hey guys! So, you're diving into the awesome world of reverse engineering and plugin development with Binary Ninja, huh? That's fantastic! Building a decompiler plugin for a custom instruction set is a seriously cool project. But, as you've discovered, getting those calling conventions just right can be a bit of a head-scratcher. Specifically, you're wrestling with a stack-based calling convention, similar to stdcall, but with a twist: arguments are pushed onto the stack from left to right. Don't worry, we'll break this down and get you sorted. Let's explore how to configure Binary Ninja's CallingConvention to accurately reflect your custom architecture and ensure your decompiler works its magic flawlessly. This guide will provide a comprehensive understanding and practical steps to conquer this challenge.

Understanding Calling Conventions: The Foundation

Before we dive into the specifics of Binary Ninja, let's quickly recap what a calling convention actually is. Think of it as a set of rules that governs how functions interact with each other. It dictates things like:

  • Argument Passing: How arguments are passed to a function (e.g., via registers, stack, or a combination). In your case, it's stack-based.
  • Argument Order: The order in which arguments are placed on the stack or in registers. This is where your left-to-right push order comes into play.
  • Return Values: How the function returns its result (e.g., in a register or on the stack).
  • Stack Management: Who's responsible for cleaning up the stack after the function call (the caller or the callee?).

These rules are crucial for ensuring that functions can correctly exchange data and control flow without causing chaos. If the calling and called functions don't agree on these rules, well, things will break, and your decompiler will likely produce incorrect or nonsensical output. Getting the calling convention right is fundamental to the accuracy of your decompilation.

So, your custom architecture's calling convention is stack-based, similar to stdcall. This means that arguments are pushed onto the stack before the function is called. The difference lies in the order of argument pushing. In stdcall, arguments are pushed from right to left, while in your architecture, they're pushed from left to right. This subtle difference is what we need to configure in Binary Ninja.

Configuring CallingConvention in Binary Ninja: Step-by-Step

Alright, let's get down to brass tacks and configure this in Binary Ninja. The CallingConvention class in the Binary Ninja API is your friend here. Here’s a breakdown of how to approach it:

  1. Access the Binary Ninja API: Make sure you have the Binary Ninja API properly set up in your plugin. You'll need to import the necessary modules, such as binaryninja.callingconvention. If you're new to Binary Ninja plugin development, start by exploring the official documentation and examples. They provide a solid foundation for understanding the API and plugin structure.
  2. Create a New CallingConvention Instance: You'll need to create a new CallingConvention object to represent your custom convention. You'll typically do this when your plugin initializes or when you're analyzing a binary that uses your custom instruction set. This is where you'll define the characteristics of your calling convention.
  3. Specify Argument Passing: Indicate that your convention uses the stack for argument passing. You might not need to explicitly set this if it's the default, but it’s always good to be explicit for clarity. The API will likely have options to specify the argument passing method.
  4. Define Argument Order (Crucial Part!): This is where you address the left-to-right argument push order. This is where things get a bit more involved. Unfortunately, Binary Ninja might not have a direct built-in option specifically for left-to-right argument pushing. This means you might need to get a little creative.
    • Option 1: Custom Code Analysis: If there isn't a direct option, you might need to write custom code analysis to handle the argument order. This involves: examining the assembly code, identifying function calls, and manually determining how the arguments are pushed onto the stack. Your decompiler plugin will then need to interpret the stack contents based on the left-to-right order.
    • Option 2: Experiment with Existing Conventions (Potentially): While it's unlikely, it's worth experimenting with existing calling conventions in Binary Ninja. Try using the closest match to your convention (e.g., stdcall) and see if you can modify its behavior through custom analysis and plugin logic.
  5. Handle Return Values: Specify how the function returns its value (e.g., in a register or on the stack). Your custom architecture will likely have a defined method.
  6. Stack Cleanup: Determine who's responsible for cleaning the stack (caller or callee) and configure your calling convention accordingly. This will impact the accuracy of your decompilation.
  7. Integrate with Your Decompiler: Use the configured CallingConvention object within your decompiler plugin. When the decompiler encounters a function call, it should use the calling convention to correctly understand how arguments are passed, what the return value is, and how the stack is managed. This is where your custom analysis and parsing code will be most important.

Let’s dig into Option 1 (Custom Code Analysis) more, since it’s the most likely approach here.

Deep Dive into Custom Code Analysis for Left-to-Right Argument Order

Since Binary Ninja might not directly support left-to-right argument pushing, you'll probably need to implement custom code analysis within your decompiler plugin. Don't worry; it's not as daunting as it sounds! Here’s a detailed breakdown of the process:

  1. Identify Function Calls: Your plugin needs to detect and identify function call instructions in your custom instruction set's assembly code. This is a crucial first step; you can do this by examining the instruction's opcode and operand structure.
  2. Analyze Stack Operations: For each function call, you'll need to analyze the surrounding assembly code to understand how arguments are pushed onto the stack. This involves examining instructions that manipulate the stack pointer (e.g., push, add esp, etc.).
  3. Determine Argument Types and Locations: Based on the stack operations, determine the types of the arguments and their locations on the stack. Remember, the left-to-right order means the first argument pushed will be at the lowest address on the stack, and so on.
  4. Create a Custom Function Object: Use the Binary Ninja API to create a custom Function object for the decompiled function. This object will hold all the information about the function, including the calling convention, arguments, and return value.
  5. Populate Argument Information: Populate the Function object's argument information. You'll need to define the argument types, names, and locations. This is where you'll leverage your analysis of the stack operations to determine the correct order and offset of each argument.
  6. Decompile the Function Body: Once you have the argument information, decompile the function body. The decompiler will use the argument information and calling convention to generate the correct C code.
  7. Handle Return Values: Determine how the function returns its value. Does it use a register, the stack, or something else? Adjust your analysis accordingly.
  8. Implement Plugin Logic: In your plugin, the critical parts include code that parses the assembly, figures out which instructions are pushing arguments, identifies the argument types, and correctly orders the arguments based on the left-to-right convention.

Example Snippet (Conceptual, not directly runnable):

from binaryninja import * # This is the Binary Ninja Python API

def analyze_function_call(bv, instruction, address):
    # 1. Identify Function Call
    if is_call_instruction(instruction):
        # 2. Analyze Stack Operations
        arguments = []
        # Example: Trace backwards from the call instruction to identify push instructions
        # This is a simplified example; actual implementation will be more complex.
        push_instructions = find_push_instructions_before_call(bv, address)

        # 3. Determine Argument Types and Locations (Left-to-Right)
        for push_instruction in reversed(push_instructions):
            operand = push_instruction.operands[0]
            argument_type = determine_argument_type(bv, operand) # Assume this function exists
            arguments.append({
                'type': argument_type,
                'location': get_argument_location(push_instruction) # Assume this function exists
            })

        # 4. Create a Custom Function Object (Simplified)
        function = Function(bv, address)

        # 5. Populate Argument Information (Left-to-Right Order)
        for i, argument in enumerate(reversed(arguments)):
            function.add_parameter(argument_type, 'arg' + str(i))

        # ... (Decompilation and other steps) ...

This example provides a conceptual outline. You'll need to fill in the implementation details based on your custom instruction set and the specific Binary Ninja API functions. Functions like is_call_instruction, find_push_instructions_before_call, determine_argument_type, and get_argument_location are placeholders. Your plugin will implement these to perform the actual analysis.

Optimization and Refinement

Optimizing for Speed: Consider caching the results of your analysis to avoid re-analyzing the same code repeatedly. Also, focus on the most common patterns and edge cases first to maximize performance.

Testing Thoroughly: Test your plugin extensively on a variety of functions and code samples to ensure its accuracy. Create test cases with different argument types, numbers, and complexities to identify any bugs.

Error Handling: Implement robust error handling. If your plugin encounters unexpected assembly code or an unrecognized instruction, it should gracefully handle the error and provide informative messages.

Conclusion: Mastering the Custom Calling Convention

Alright, guys! Setting up the custom CallingConvention in Binary Ninja might seem like a complex task, but with these steps and a bit of effort, you'll be well on your way to successfully decompiling code for your custom architecture. The key is to understand the calling convention of your custom instruction set and implement custom code analysis to handle any unique aspects, such as the left-to-right argument push order. Remember to leverage the Binary Ninja API, experiment, test thoroughly, and don’t be afraid to dive deep into the assembly code. The world of reverse engineering is full of exciting challenges, and mastering custom calling conventions is a critical skill. Good luck with your plugin development, and happy coding!
